14 Conditions of usable media
Roll media can be used in this product.
• Be cautious of expansion and contraction of media from temperature and humidity.
After opening an unopened media, leave the media for approximately 30 minutes to adjust to environments.
• Do not use media with folds, scratches, tears, curvatures, winding curl and weaving.
• Do not leave a roll media set in this product for a long time. The media can be curled becoming unsuitable for printing.
When not using for a long time, remove a roll media and store in its original package box.
Conditions of usable media
Usable size
Maximum
width
630 mm (If paper tube > media width, then
paper tube width)
Maximum
thickness
Head height when Low 0.3 mm
Head height when High 1.3 mm
Roll outer
diameter
150 mm
Paper tube
diameter
2 or 3 inches
Weight 9 kg or less
Cautions when handling media
