66 Replacing absorption material for the flushing box
[3]
Click [CR Maintenance].
• The MSM remote panel opens.
Note
MSM can be launched directly.
"Launching MSM" on page 11
[4]
Click [Start].
[5]
Short press the operation key on the operation panel.
• The carriage moves to the maintenance position inside the front
cover.
[6]
Open the front cover.
[7]
Remove the absorption material for the flushing box.
• Pull the tab up of the absorption material for the flushing box, and
release the hook.
When removing the absorption material for the flushing box, be
cautious of ink drops.
[8]
Attach new absorption material for the flushing box.
Press!
To Next Page
