NAD T 752 - ELECTRICAL PARTS LIST; VIDEO BOARD COMPONENTS

55
Reference No. Part No. Description
CAPACITORS
C790-C791 22-3123072-00-41 CAP ELEC LP 12000uF 80V 20%
C781-C789 22-4210402-00-31 CAP MPF 0.1uF 63V 5%
RESISTORS
R784-R785 23-2228232-00-00 RES MO 0.22 OHM 5% 1/2W
R790,R793
23-4228280-08-20 RES CE 0.22 OHM 5% 5W
R781-R783
23-5228330-00-00 RES FUSIBLE 0.22 OHM 10% 1/2W
SPEAKER BOARD
SPEAKER TERMINALS
M5101 34-3000022-00-60 SPEAKER TER 4P R/B W/O PLUG
PT-430A-03
M8101 34-3000021-00-60 SPEAKER TER 6P R/B W/O PLUG
PT-630A-03
S-VIDEO BOARD
DIODES
D4101-D4107 20-0000000-00-13 DIODE SW 4NS DO35 IN4148
TRANSISTORS
Q4101,Q4103,Q4122 21-0000120-70-14 XTR NPN HFE 68 30MHz SPT
DTC144ES
Q4102 21-0000450-70-14 XTR NPN 68 250MHz SPT DTA144ESA
Q4107-Q4112,Q4116-Q4119 21-0100370-70-14 XTR PNP HFE 270-560 140MHz
2SA933AS
Q4113-Q4114,Q4121,Q4124-Q4125, 21-0000360-00-00 XTR NPN HFE200-700 30MHz
Q4128-Q4130 2SC2878A
Q4115,Q4126-Q4127 21-0000390-70-14 XTR NPN HFE270-560 180MHz
2SC1740S
Q4120,Q4123 21-0000380-70-14 XTR NPN HFE20 250MHz DTC-123ESA
CAPACITORS
C4101-C4107,C4109-C4111,C4113-C4115, 22-3226052-00-43 CAP ELEC SS 2.2uF 50V 20%
C4117-C4120,C4153,C4157
C4108,C4112,C4116,C4156 22-3471012-00-28 CAP ELEC GR 470uF 10V 20%
C4123-C4124 22-3221012-00-43 CAP ELEC SS 220uF 10V 20%
C4133,C4141 22-3106052-00-43 CAP ELEC SS 1uF 50V 20%
C4134,C4145,C4149 22-3101012-00-43 CAP ELEC SS 100uF 10V 20%
C4136,C4146 22-4247402-00-31 CAP MPF 0.47uF 63V 5%
C4137,C4144 22-3477052-00-43 CAP ELEC SS 0.47uF 50 20%
C4138 22-7300210-00-01 CAP VC 30pF 20%
C4150,C4158 22-3470022-00-43 CAP ELEC SS 47uF 16V 20%
C4151 22-3100022-00-43 CAP ELEC SS 10uF 16V 20%
INDUCTORS
L4101 24-0569107-00-28 IND CHOKE 5.6uH 10%
L4102 24-0220107-00-28 IND CHOKE 22uH 10%
