NAD T 752 - Page 58

56
Reference No. Part No. Description
ICS
U4101 27-5574763-21-02 I.C. OSD LC74763-9012
U4102,U4103 27-5076250-21-23 I.C. AV SWITCH BA7625
U4104 27-9496600-21-02 I.C. QUAD BILATERAL SWITCH LC4966
CRYSTALS
X4101 28-5143200-06-19 CRYSTAL 14.318MHz 30ppm HC-49S
X4102 28-5177200-06-19 CRYSTAL 17.73447MHz 30ppm HC-49S
DIN JACKS
M411-M418 34-4110300-00-60 DIN JACK 1 BLACK MD-113
TRIGGER BOARD
DIODE
D351 20-3251902-00-01 DIODE ZENER BZX55 5.1V 1/2W 5%
TRANSISTOR
Q351 21-0000380-70-14 XTR NPN HFE20 250MHz DTC-123ESA
REGULATORS
U351-U352 27-3001291-07-14 I.C. VOLT REG 12V 100mA 78L12
JACKS
M351 34-4020420-00-60 RCA JACK 2 R-W GOLD RS-253-04
M353,M355 34-4310300-00-60 PHONE JACK 1 BLACK 3.5mm RIGHT
ST-030-07
M354,M352 34-4320300-00-67 PHONE JACK 3.5mm 2P RIGHT
JY-3552-01-330
SWITCH
S351 35-4102209-00-67 SW SLIDE 2P2T JSK022N09-G09
VIDEO-6 BOARD
CAPACITORS
C4401-C4403 22-3226052-00-44 CAP ELEC SS 2.2uF 50V 20%
JACKS
J4401 34-4510302-00-60 PHONE JACK D6.3 1 ST-016S-01
M4401 34-4010000-01-60 RCA JACK 1 YELLOW GOLD
RS-105G/Y
M4402 34-4110300-00-60 DIN JACK 1 BLACK MD-113
M4403 34-4010200-01-60 RCA 1 WHITE GOLD RS-105AG/W
M4404 34-4010100-01-60 RCA JACK 1 RED GOLD RS-105AG/R
VIDEO BOARD
TRANSISTORS
Q4201-Q4203 21-0100370-70-14 XTR PNP HFE 270-560 140MHz
2SA933AS
