W415-2005 / A / 06.26.19
EN
18
installation
3.5 rubber feet installation
A. Place the appliance face down on a soft surface.
B. Remove the screws (4 for NEFL42/50/60HS/HI; 6 for NEFL72/100HS/HI) from the bottom of the
appliance (Fig. 3-10). Set the screws aside.
C. Install the rubber feet (supplied) (4 for NEFL42/50/60HS/HI; 6 for NEFL72/100HS/HI) using the screws
previously removed in step B (Fig. 3-11).
The screws for installing the rubber feet are secured to the appliance. Removal of the screws is
necessary for installing the rubber feet.
note:
Fig. 3-10
Fig. 3-11
C x 4
NEFL42/50/60HS/HI
Screws Illustrated
NEFL42/50/60HS/HI
Rubber Feet Illustrated
Fig. 3-10
Fig. 3-11
C x 6
NEFL72/100HS/HI
Screws Illustrated
NEFL72/100HS/HI
Rubber Feet
Illustrated
