Napoleon purview 42 Series User Manual

W415-2005 / A / 06.26.19
EN
24
5.0 fi nishing
5.1 front glass removal / installation
• Power supply service must be completed prior to fi nishing to avoid reconstruction.
• Heat vents and air openings cannot be covered in any circumstances.
!
WARNING
A. With one hand on the front glass to prevent it from falling, remove the two screws (1 per side) from the
top of the appliance (Fig. 5-1). Set the screws aside.
B. Carefully lift the front glass up and away from the appliance (Fig. 5-2 and 5-3). Place it face down on a
soft, non-abrasive surface.
C. Reverse these steps to install the front glass.
Fig. 5-1
Fig. 5-2
The glass surround must be removed and the appliance must be secured in its fi nal location before the crystal
embers are installed.
A. Clean crystal embers with mild dish soap. Then drain, rinse, and dry
the crystal embers before placing them into the tray.
B. Carefully place crystal embers into the bottom tray on the front of the
appliance as illustrated. Apply an even layer from side to side.
C. Reinstall the front glass.
5.2 crystal ember installation
NEFL60HS illustrated
NEFL60HS illustrated
Fig. 5-3
1
2
NEFL60HS illustrated
