W415-2005 / A / 06.26.19
EN
4
table of contents
1.0 general information 5
1.1 dimensions (NEFL42/50/60HS/HI) 5
1.2 dimensions (NEFL72/100HS/HI) 6
1.3 rating plate information 7
1.4 label location 7
1.5 listing approvals 8
1.6 general instructions 8
1.7 unpacking and testing the appliance 9
1.8 hardware list 9
2.0 appliance placement 10
2.1 grounding the appliance 10
3.0 installation 11
3.1 minimum clearance to combustibles 11
3.2 framing 12
3.3 wall mount installation 13
3.4 recessed pre-installation 15
3.4.1 fully recessed installation 15
3.4.2 partially recessed installation 16
3.4.3 into a mantel 17
3.5 rubber feet installation 18
4.0 electrical information 19
4.1 hard-wiring installation 19
4.2 wiring diagram (NEFL42HS/HI) 20
4.3 wiring diagram (NEFL50/60HS/HI) 21
4.4 wiring diagram (NEFL72HS/HI) 22
4.5 wiring diagram (NEFL100HS/HI) 23
5.0 finishing 24
5.2 crystal ember installation 24
5.1 front glass removal / installation 24
6.0 operating instructions 25
6.1 operating touch display panel and remote control 25
7.0 maintenance 27
7.1 remote battery installation 27
8.0 replacement parts 28
8.1 NEFL42/50/60/72/100HS/HI overview 29
9.0 troubleshooting 30
10.0 warranty 32
11.0 notes 33
The information throughout this manual is believed to be correct at the time of printing. Wolf Steel Ltd. reserves
the right to change or modify any information within this manual at any time without notice. Changes, other than
editorial, are denoted by a vertical line in the margin.
note:
