framing
The has been designed to be installed mid-way up a wall. If installing this appliance close to the fi nished
fl oor, the appliance must be raised a minimum of 2" (51mm) (unobstructed) to allow for full rotation of the control
door. It is not necessary to install fl oor protection. Although the appliance fi ts between studs, most jurisdictions
will not allow a “hole” in the warm air envelope of a residential structure. It is recommended to build either an
interior or exterior chase with a minimum depth of 7" (178mm).
It is best to frame your appliance after it is positioned and the vent system is installed. Frame to local building
codes.
To install the appliance face fl ush with the fi nished surface, position the framework to accommodate the thickness
of the fi nished surface. Use 4 fl at-head screws to secure the nailing tabs to the framing. Cover the nailing tabs
with your fi nishing material.
4.0 framing
!
WARNING
• Risk of fi re!
• In order to avoid the possibility of exposed insulation or vapour barrier coming in contact with the appliance
body, it is recommended that the walls of the appliance enclosure be “fi nished” (i.e. drywall / sheetrock),
as you would fi nish any other outside wall of a home. This will ensure that clearance to combustibles is
maintained within the cavity.
• Do not notch the framing around the appliance stand offs. Failure to maintain air space clearance may cause
over heating and fi re. Prevent contact with sagging or loose insulation or framing and other combustible
materials. Block opening into the chase to prevent entry of blown-in insulation. Make sure insulation and
other materials are secured.
• When constructing the enclosure, allow for fi nishing material thickness to maintain clearances. Framing or
fi nishing material closer than the minimums listed must be constructed entirely of non-combustible materials.
Materials consisting entirely of steel, iron, brick, tile, concrete, slate, glass or plasters, or any combination
thereof are suitable. Materials that are reported as passing ASTM E136, standard test method for behaviour
of materials in a vertical tube furnace at 1382ºF (750ºC) and UL763 shall be considered non-combustible
materials.
• Minimum clearance to combusibles must be maintained or a serious fi re hazard could result.
• The appliance requires a minimum enclosure height. Measure from the appliance base.
• If steel stud framing kits with cement board are provided, or specifi ed in the installation instructions, they
must be installed.
• If specifi ed in the installation instruction, fi nishing must be done using a non-combustible board, ceramic tile,
marble, etc. Do NOT use wood or drywall. Any fi re rated drywall is not acceptable.
When using optional fi nishing accessories, the framing dimensions and fi nishing materials may differ from
what is outlined in the section below; refer to the leafl et instructions supplied in the accessory kit for specifi c
framing and fi nishing specifi cations.
note:
