W415-2350 / 10.28.19
EN
4
table of contents
NOTE: Changes, other than editorial, are denoted by a line in the margin.
1.0 general information 5
1.1 dimensions 7
1.2 rating plate information 7
2.0 venting 8
2.1 cold climate 8
2.2 venting lengths and components 8
2.3 vent terminal clearances 9
2.4 horizontal termination 10
2.5 vertical termination 11
3.0 installation 12
3.1 horizontal installation 12
3.2 vertical installation 13
3.3 using fl exible vent components 13
3.3.1 horizontal air terminal installation 14
3.3.2 vertical air terminal installation 15
3.3.3 appliance vent connection 15
3.4 gas installation 16
3.5 mobile home 16
4.0 framing 17
4.1 minimum clearance to combustibles 18
4.2 minimum enclosure clearances 19
4.3 nailing tab installation 20
4.4 stand-off assembly 20
5.0 finishing 21
5.1 mounting cabinet installation 21
5.2 safety barrier installation and removal 23
5.3 door removal 24
5.4 frame/front installation 25
5.5 glass media installation 26
5.6 LK8 light installation (optional) 27
6.0 electrical information 28
6.1 hard wiring connection 28
7.0 operation 29
8.0 adjustments 30
8.1 gas pressure adjustment 30
8.2 venturi adjustment 30
8.3 fl ame characteristics 30
9.0 maintenance 31
9.1 annual maintenance 32
9.2 care of glass 32
9.3 door glass replacement 33
10.0 replacement parts 34
10.1 overview 35
10.2 valve train assembly 36
11.0 accessories 37
12.0 troubleshooting 38
13.0 warranty 40
14.0 notes 41
