W415-2350 / 10.28.19
EN
24
fi nishing
Before the glass door can be removed, the optional frame/front must be
removed.
The glass door is secured to the top front edge of the
fi rebox. Pull the handles of the latches forward, then lift
the hooks out from the slots in the door frame to release
the top of the door. Then, pivot forward until the top
edge of the door clears the front of the appliance. Next
gripping the sides of the door lift the door out from the
retainer along the bottom of the door.
Reverse these steps to re-install the screen and door.
Ensure safety screen is installed correctly.
OPEN
CLOSED
5.3 door removal
!
WARNING
• Glass may be hot. Do not touch glass until cooled.
• If equipped with door latches that are part of a safety system, they must be properly engaged. Do not
operate the appliance with latches disengaged.
• Facing and/or fi nishing materials must not interfere with air fl ow through air openings, louvre openings,
operation of louvres, or doors/access for service. Observe all clearances when applying combustible
materials.
• Before door is removed, turn the appliance off and wait until appliance is cool to the touch. Doors are heavy
and fragile so handle with care.
