9010F Fast 15-5
Noise level
Preselector OFF, preamplifier OFF
Preselector OFF, preamplifier ON
Preselector ON, preamplifier OFF
Preselector ON, preamplifier ON
9 to 150 kHz < -13 dBuV (QP 1s)
(200 Hz RBW)< -16 dBuV (AV 1s)
0.15 to 30 MHz< 5 dBuV (QP 1s)
(9 kHz RBW) < 0 dBuV (AV 1s)
9 to 150 kHz < -27 dBuV (QP 1s)
(200 Hz RBW) < -30 dBuV (AV 1s)
0.15 to 30 MHz < -9 dBuV (QP 1s)
(9 kHz RBW) < -14 dBuV (AV 1s)
9 to 150 kHz < -7 dBuV (QP 1s)
(200 Hz RBW) < -10 dBuV (AV 1s)
0.15 to 30 MHz< 5 dBuV (QP 1s)
(9 kHz RBW) < 0 dBuV (AV 1s)
9 to 150 kHz < -24 dBuV (QP 1s)
(200 Hz RBW) < -27 dBuV (AV 1s)
0.15 to 30 MHz< -7 dBuV (QP 1s)
(9 kHz RBW) < -12 dBuV (AV 1s)
Spurious response
(PK 100ms)
< -7 dBuV, < 3 dBuV above 150 kHz
Measuring Detectors
(Four simultaneous in stand-alone,
all with PMM Emission Suite SW)
Peak, Quasi-peak, Average, RMS, RMS-Average, C-
Average, APD
(1)
.
Smart Detector function (with 9030, 9060 and 9180)
(1)
Level measuring time
(Hold Time)
0.1 ms to 120 sec. (CISPR 16-1-1 as default)
Display units
Stand alone
(80 to 120 dB selectable dynamic)
With PMM Emission Suite SW on PC
(80 to 200 dB selectable dynamic)
dBm, dBµV
dBm, dBµV, dBµA, dBpW, dBµV/m, dBµA/m, dBpT
Spectrum
Span/division
From 100 Hz to 3 MHz
