PMM 9030/9060/9180 Frequency Extension 11-3
11.5 PMM 9030
Main Specifications
Table 11-1 lists the PMM 9030 performance specifications.
The following conditions apply to all specifications:
• thanks to its analogue+digital architecture, the PMM 9030 needs only
15 minutes of warm-up period before to operate in full-compliance
with specifications;
• the ambient temperature shall be 0°C to 40°C
TABLE 11-1 PMM 9030 Main Specifications
Frequency range
Resolution
Frequency Accuracy
30 MHz to 3 GHz (CISPR-16-1-1 Full-Compliance)
100 Hz
< 2 ppm
RF input
VSWR
≥ 10 dB RF att.
0 dB RF att.
Attenuator
Preamplifier gain
Z
in
50 Ω, N fem.
< 1,2; <2 over 1 GHz
< 2,0
0 dB to 55 dB (5 dB steps)
10 dB (selectable)
Max input level
(without equipment damage)
Sinewave AC voltage Pulse
spectral density
137 dBuV (1 W)*
97 dBµV/MHz
Preselector
Three tracking filters;
One bandpass filter
30,0 MHz to 96,6 MHz
96,6 MHz to 311,0 MHz
311,0 MHz to 1,0 GHz
1 GHz to 3 GHz
IF bandwidth
6 dB bandwidth
CISPR 16-1-1 bandwidth (6 dB)
3, 10, 30, 100, 300 kHz, 1 MHz (Bimp)
120 kHz
(*) with MIN ATT ≥ 10 dB
