15-6 9010F Fast
Measurement accuracy
S/N > 20 dB
10 Hz to 9 kHz± 1.0 dB Typ
9 kHz to 30 MHz± 0.8 dB
Scan time
Sweep mode
(Full CISPR: preselector ON,
QP detector)
A band
(9 to 150 kHz)
(200 Hz RBW)
B band
(150 kHz to 30 MHz)
(9 kHz RBW)
Analyzer mode
(preselector OFF, Peak detector)
A band ( 9 to 150 kHz)
200 Hz RBW
B band (150 kHz to 30 MHz)
300 kHz RBW
9, 10 kHz RBW (gapless)
< 5 s (Hold time 1s)
< 8 s (Hold time 2s)
< 20 s (Hold time 1s)
< 38 s (Hold time 2s)
< 0.45s (Hold time 100 ms)
< 1 s (Hold time 1 s)
< 1 s (Hold time 50ms)
RF output
Frequency range
Level range
Level accuracy (10 Hz to 30 MHz)
Tracking (manual mode) & CW generator
Z
out
50 Ω,BNC fem.
10 Hz to 50 MHz
60 to 90 dBµV (0.1 dB step)
0.5 dB
Auto Calibration
Internal reference source
Stand-alone display and measure
functions
Marker, marker peak, marker to center, highest peaks, move
peak to Analyzer & Manual modes.
Store load:
- up to 11 traces (sweep mode)
- two panels
- 4 conversion factors
Built-in limits: CISPR 11, 14, 22.
Battery charge and voltage.
Display style, contrast, backlight.
Click functions (optional)
(1)
I/O Interface Out
RS-232
High speed Optical (2 channels)
USB rear (front for future extension)
User port (Drives PMM LISNs and accessories)
Bluetooth (optional)
IEEE-488 (optional)
