1-4 General Information
Noise level (preamplifier ON)
9 to 150 kHz (200 Hz BW)
150 kHz to 30 MHz (9 kHz BW)
< -8 dBµV (QP); < -15 dBµV (AV)
< -4 dBµV (QP); < -10 dBµV (AV)
Measuring Detectors
Peak, Quasi-peak, Average, RMS, RMS-Average, CISPR-
Average, APD and Smart Detector function
Level measuring time
Peak, Quasi-peak, Average, RMS
(simultaneous detectors)
1 ms to 30 sec. (CISPR 16-1-1 default)
Display units
Spurious response
dBm, dBµV (as stand-alone);
dBm, dBµV, dBµV/m, dBmA, dBmA/m, dBpW (through 9010
SW Utility on PC)
< 0 dBuV, < 10 dBuV over 150 kHz
Spectrum
Span/division
From 100 Hz to 3 MHz
Measurement accuracy
S/N > 20 dB
10 Hz to 9 kHz ± 1.0 dB typical
9 kHz to 30 MHz ± 1.0 dB
Demodulation
Built-in AM demodulator (earphones jack output)
RF output
(Tracking Generator)
Frequency range
Level
Level accuracy (10 Hz to 30 MHz)
Z
out
50 Ω, BNC fem.
10 Hz to 50 MHz
60 dBµV to 90 dBµV (0.1 dB steps)
± 0.5 dB
I/O Interface
USB 2.0 (rear); USB 2.0 (front ; only for future
implementation); RS-232; High Speed Optical Link (2
channels; 2nd channel for future implementation); User Port
(for LISNs connection, etc.); Bluetooth through optional
adapter; IEEE-488 (GPIB) optional
Operating temperature
0° to 40°C
Power supply
10 - 15 Volt DC, 2,5A; Li-Ion interchangeable battery (8 h
operations, typical)
Dimensions
235 x 105 x 335 mm
Weight
4.1 kg
