© National Instruments | 2-1
2
Installation and Configuration
This chapter describes how to prepare and operate the PXIe-1095 chassis.
Before connecting the chassis to a power source, read this chapter and the Read Me First: Safety
and Electromagnetic Compatibility document included with your kit.
Safety Information
Caution Before undertaking any troubleshooting, maintenance, or exploratory
procedure, carefully read the following caution notices.
Protection equipment may be impaired if equipment is not used in the manner
specified.
This equipment contains voltage hazardous to human life and safety, and is capable of inflicting
personal injury.
Caution High leakage current present when operating dual power supplies at 400
to 440 Hz. Connect the chassis to earth ground before connecting to AC power.
• The facility installation shall provide a means for connection to protective earth; and
• Qualified personnel shall install a protective earthing conductor from the chassis
protective earth terminal (# 8 -32 SEMS screw) on the rear to the protective earth
wire in the facility.
Protective earth terminal wiring
Grounding wire 2.1 mm
2
(14 AWG)
Ring lug # 8
Protective earth terminal torque 1.13 N
· m (10 lb · in.)
• Chassis Grounding—The chassis requires a connection from the premise wire safety
ground to the chassis ground. The earth safety ground must be connected during use of this
equipment to minimize shock hazards. Refer to the Connecting the Safety Ground section
for instructions on connecting safety ground.
• Live Circuits—Operating personnel and service personnel must not remove protective
covers when operating or servicing the chassis. Adjustments and service to internal
components must be undertaken by qualified service technicians. During service of this
