2-6 | ni.com
Chapter 2 Installation and Configuration
Rack Mounting
Rack mount applications require optional rack mount kits available from National Instruments.
Refer to the instructions supplied with the rack mount kits to install your PXIe-1095 chassis in
an instrument rack.
Note You may want to remove the feet or carrying handle from the PXIe-1095
chassis when rack mounting.
Figure 2-3. PXIe-1095 Rack Mount Kit Components
1 Front Rack Mount 2 Rear Rack Mount
1
2
