PXIe-1095 User Manual
High Reliability
• 0 to 55 °C extended temperature range
• Power supply, temperature, and fan monitoring
• Field replaceable fans
• Dual redundant, hot-swappable power supplies
Multi-Chassis Support
• PXI Express System Timing Slot for tight synchronization across multiple chassis
• Switchless CLK10 routing
Optional Features
• Timing and synchronization upgrade
• Front and rear rack-mount kits
• Replacement power supply
• EMC filler panels
• Slot blockers for improved cooling performance
• Factory installation services
• Replacement fan kit
Chassis Description
Figures 1-1 and 1-2 show the key features of the PXIe-1095 chassis front and back panels.
Figure 1-1 shows the front view of the chassis. Figure 1-2 shows the rear view of the chassis.
Refer to Figure 2-2, PXIe-1095 Chassis Vents, for chassis vent locations.
