3-6 | ni.com
Chapter 3 Maintenance
Figure 3-2. Replacing Rear Fan Module
Figure 3-3. Internal Fan Harness
1 Fan Harness Plug
2 PXIe-1095 Chassis
3 PXI Module Fan Assembly
4 Rear Chassis Feet (2x)
5 Mounting Screws (8x)
1 Fan Receptacle 2 Fan Harness Plug
1
2
3
4
5
1
2
