A-2 | ni.com
Appendix A Pinouts
System Controller Slot Pinouts
Table A-1. XP1 Connector Pinout for the System Controller Slot
Pins Signals
A GND
B 12V
C 12V
D GND
E 5V
F 3.3V
G GND
Table A-2. XP2 Connector Pinout for the System Controller Slot
Pin A B ab C D cd E F ef
1 2PETp1 2PETn1 GND 2PERp1 2PERn1 GND 2PETp2 2PETn2 GND
2 2PETp3 2PETn3 GND 2PERp3 2PERn3 GND 2PERp2 2PERn2 GND
3 2PETp4 2PETn4 GND 2PERp4 2PERn4 GND 2PETp5 2PETn5 GND
4 2PETp6 2PETn6 GND 2PERp6 2PERn6 GND 2PERp5 2PERn5 GND
5 2PETp7 2PETn7 GND 2PERp7 2PERn7 GND 2PETp8 2PETn8 GND
6 2PETp9 2PETn9 GND 2PERp9 2PERn9 GND 2PERp8 2PERn8 GND
7 2PETp10 2PETn10 GND 2PERp10 2PERn10 GND 2PETp11 2PETn11 GND
8 2PETp12 2PETn12 GND 2PERp12 2PERn12 GND 2PERp11 2PERn11 GND
9 2PETp13 2PETn13 GND 2PERp13 2PERn13 GND 2PETp14 2PETn14 GND
10 2PETp15 2PETn15 GND 2PERp15 2PERn15 GND 2PERp14 2PERn14 GND
