National Instruments sbRIO-9687 User Manual

Table 34. LVTTL Lines (Continued)
GPIC Signal Onboard Function Direction (to
GPIC)
Active State Disconnecting
Resistor
DIO3 Over Range 3 Input Low R150
DIO4 Over Range 4 Input Low R142
DIO5 Over Range 5 Input Low R134
DIO6 Over Range 6 Input Low R133
DIO7 Over Range 7 Input Low R129
DIO8 Feedback_0.0 Input Low/High R123
DIO9 Feedback_0.1 Input Low/High R114
DIO10 Feedback_0.2 Input Low/High R113
DIO11 Feedback_0.3 Input Low/High R104
DIO12 Feedback_0.4 Input Low/High R96
DIO13 Feedback_0.5 Input Low/High R95
DIO14 Hall_0.0 Input Low R86
DIO15 Hall_0.1 Input Low R78
DIO16 Hall_0.2 Input Low R65
DIO17 Feedback_1.0 Input Low/High R72
DIO18 Feedback_1.1 Input Low/High R73
DIO19 Feedback_1.2 Input Low/High R79
DIO20 Feedback_1.3 Input Low/High R87
DIO21 Feedback_1.4 Input Low/High R97
DIO22 Feedback_1.5 Input Low/High R98
DIO23 Hall_1.0 Input Low R105
DIO24 Hall_1.1 Input Low R115
DIO25 Hall_1.2 Input Low R124
DIO26 SCL (I
2
C RH sensor) Input/Output — R125
DIO27 SDA (I
2
C RH sensor) Input/Output — R130
sbRIO-9687 User Manual | © National Instruments | 39
