Debugging LEDs
• 3 debugging LEDs
• 1 power LED
Configuration options
• Onboard DIP switches for configuration
• 0 Ω resistors for configuration
• Pads for current-sensing resistors on analog inputs
• Easy access for changing low pass filter components
Connectors
The following table lists the sbRIO-9687 connectors and recommended mating connectors.
Refer to the manufacturer for information about using and matching these connectors.
Table 1. sbRIO-9687 Connector Types
sbRIO-9687
Connector
Reference
Designator
Description Recommended Mating
Connector
24 V power J35 2-pin header Weidmuller (1930050000)
SKiiP 3 (x7) J36, J37, J38, J39,
J40, J41, J42
14-pin header On-Shore Technology, Inc.
(101-146)
SKiiP 4 (x7) J16, J17, J18, J19,
J20, J21, J22
25-pin Dsub header Kycon (K85X-BA-25S-30)
Semikube GB (x6) J29, J30, J31, J32,
J33, J34
20-pin header On-Shore Technology, Inc.
(101-206)
Semikube GD (x2) J24, J25 34-pin header On-Shore Technology, Inc.
(101-346)
SKiiP 3 GD (x2) J26, J27 26-pin header On-Shore Technology, Inc.
(101-266)
Simultaneous AI
(x2)
J5, J11 26-pin header Weidmuller (B2CF
3.50/26/180LH SN BK BX)
Feedback input (x2) J6, J10 24-pin header Weidmuller (B2CF
3.50/24/180LH SN BK BX)
Scanned AI, AO J14 26-pin header Weidmuller (B2CF
3.50/26/180LH SN BK BX)
4 | ni.com | sbRIO-9687 User Manual
