National Instruments sbRIO-9687 User Manual

Table 37. J6 Feedback Connector Pinout
Pin Signal Pin Signal
1 GND 13 GND
2 Feedback_0.0_A 14 Feedback_0.0_B
3 Feedback_0.1_A 15 Feedback_0.1_B
4 Feedback_0.2_A 16 Feedback_0.2_B
5 GND 17 GND
6 Feedback_0.3_A 18 Feedback_0.3_B
7 Feedback_0.4_A 19 Feedback_0.4_B
8 Feedback_0.5_A 20 Feedback_0.5_B
9 GND 21 GND
10 Hall_0.0 22 Hall_0.1
11 Hall_0.2 23 GND
12 +5 V 24 +5 V
Table 38. J10 Feedback Connector Pinout
Pin Signal Pin Signal
1 GND 13 GND
2 Feedback_1.0_A 14 Feedback_1.0_B
3 Feedback_1.1_A 15 Feedback_1.1_B
4 Feedback_1.2_A 16 Feedback_1.2_B
5 GND 17 GND
6 Feedback_1.3_A 18 Feedback_1.3_B
7 Feedback_1.4_A 19 Feedback_1.4_B
8 Feedback_1.5_A 20 Feedback_1.5_B
9 GND 21 GND
10 Hall_1.0 22 Hall_1.1
sbRIO-9687 User Manual | © National Instruments | 43
