Chapter 3 Configuring Your SCXI Hardware and Software
Getting Started with SCXI 3-48 www.ni.com
Tables 3-36 and 3-37 show the SCXI-1163R jumper configurations.
Table 3-36. SCXI-1163R Device-Type Jumper Configuration
Jumper Description
Configuration for
DIO Device
Configuration for
MIO Device
Configuresrear connector.
Factory-default position is
for DIO devices.
Configuresrear connector.
Factory-default position is
for DIO devices.
Configures SERDATOUT
line for a DIO or MIO
device. Factory-default
position is for DIO
devices.
PAR —Use this setting to
disconnect SERDATOUT
line and for parallel mode.
W2
D
M
D
M
W3
M
D
M
D
W5
MIO
DIO
PAR
MIO
DIO
PAR
DIO
PAR
MIO
