Nautel VX150 - Page 111

StockCode:
NARF80A
Page 31 of 51
Description
:
Final Assy, VX1.5/2,
Component Lvl, StockCode Reference DesignationDescription
JU85
02
Conn, Header, Shrouded, 0.050" 30pos, Dual Row, Go J05
LA72
02
Bead, Ferrite, SMT, 120 Ohm at 100MHz, 1.3A, 0402 L02
LS56
02
Inductor, SMT, 3.3uH, 5.6A,RMS L01, L03, L04
QDDS02
02
Diode, SMT, Schottky, 40V, 1A, SMA CR04
QDSS01
02
Diode, SMT, Schottky, 30V, 0.2A, SOD-323 CR03
QDZS11
02
Diode, SMT, Zener, 5.6V, 1.5W, SMA, 403D CR01, CR02, CR05, CR06
RAD23
02
Resistor, SMT, MF, 681 Ohms, 1% 1/4W R011, R052
RAF01
02
Resistor SMT MF 0.0 Ohm Jumper 0402 R034, R095, R099, R100, R123
RAF18
02
Resistor SMT MF 22.1 Ohm 1% 1/16W 0402 R090, R103, R144, R145
RAF26
02
Resistor SMT MF 100 Ohm 1% 1/16W 0402
R003, R018, R037, R038, R048, R069, R082, R097, R113,
R131, R153
RAF38
02
Resistor SMT MF 1000 Ohm 1% 1/16W 0402
R007, R008, R009, R014, R015, R016, R031, R032, R044,
R045, R046, R060, R061, R062, R109, R110,, R117, R125,
R127, R128, R129, R136, R137, R149, R150
RAF50
02
Resistor SMT MF 10.0K Ohm 1% 1/16W 0402
R004, R005, R012, R019, R023, R025, R026, R027, R033,
R035, R039, R041, R042, R050, R051, R053,, R056, R057,
R058, R066, R070, R073, R074, R075, R080, R085, R086,
R089, R093, R096, R098, R101,, R102, R104, R105, R106,
R107, R108, R114, R119, R126, R134, R135, R146, R147,
R148
RAF52
02
Resistor SMT MF 15.0K Ohm 1% 1/16W 0402 R021, R029, R079, R118
RAF56
02
Resistor SMT MF 33.2K Ohm 1% 1/16W 0402 R055
RAF57
02
Resistor SMT MF 39.2K Ohm 1% 1/16W 0402
R006, R013, R020, R043, R059, R072, R088, R111, R116,
R141, R151
RAF59
02
Resistor SMT MF 56.2K Ohm 1% 1/16W 0402 R024, R028, R049, R054, R094
RAF63
02
Resistor SMT MF 121K Ohm 1% 1/16W 0402 R071
RAF66
02
Resistor SMT MF 221K Ohm 1% 1/16W 0402 R087, R120
RAF74
02
Resistor SMT MF 1.00M Ohm 1% 1/16W 0402 R001, R030
RAF87
02
Resistor SMT MF 3740 Ohm 1% 1/16W 0402 R010, R017, R047, R063
RAF93
02
Resistor SMT MF 7.15K Ohm 1% 1/16W 0402 R077, R083, R132, R139
RAF94
02
Resistor SMT MF 3.57K Ohm 1% 1/16W 0402 R078, R133
RAF95
02
Resistor SMT MF 4.12K Ohm 1% 1/16W 0402 R084, R091, R140, R142
RAF96
02
Resistor SMT MF 2.10K Ohm 1% 1/16W 0402 R092, R143
US12
02
IC, SMT, Rectifier, Bridge, 400V, 0.5A, SOIC-4 U02, U08, U21, U26
US58
02
IC, SMT, 24Bit Audio Codec, SPI, I2C, TSSOP28 U06
US59
02
IC, SMT, 10-Bit A/D Converter, 4Ch, 200KSPS, 10-VS U03
