Nautel VX150 - Page 112

StockCode:
NARF80A
Page 32 of 51
Description
:
Final Assy, VX1.5/2,
Component Lvl, StockCode Reference DesignationDescription
US60
02
IC, SMT, ADC 16 Bit, 2Ch, 750KSPS, 16-WQFN U17
UT170
02
IC, SMT, Adj. DC to DC Inverting Reg, 2.4A, 16-LFC U20
UT171
02
IC, SMT, Op AMP, Dual, Low Noise, Bipol Supply, 8- U01, U04, U09, U13, U15, U18, U19, U23
UT172
02
IC, SMT, Precision Diff Amp, 8-MSOP U05, U10, U16, U25
UT178
02
IC, SMT, Rail to Rail Dual Op-amp, Wide BW, SOIC8 U14, U24
UX66
02
IC,SMT,Linear Regulator,150mA Adj.,MSOP-8 U07, U11, U12
UX83
02
IC,SMT,2.5V Reference,0.1%,SOT -23-6 U22
NAPI193
01
Front Panel User Interface Pwb Assy A05
CCFS04
02
Cap,SMT,Ceramic,0.01uF,10%,50V,X7R,0603 C02, C03
CCFS07
02
Cap,SMT,Ceramic,0.1uF,10%,50V,X7R,0805 C04
CCJ18
02
Cap,SMT,Ceramic,22uF,20%, 25V,X5R,0805 C06
CT112
02
Cap, SMT, Elect, Alum Polymer, 100uF, +/- 20%, 25V C05
JA140
02
Conn, USB, Vertical Mount, Type A, PWB J04
JQ55
02
Conn, Header, Ribbon Cbl, 20 Pin J03
JQ97
02
Conn, Header, SATA, Vert, PWB J01
JU96
02
Conn, Header, Shrouded, 0.050" 20pos, Dual Row, Go J02
LS18
02
Inductor,SMT.2.2uH,600ma,1210 L01
QM77
02
Diode, LED, RED, Rectangular, TH, 5mm x 2mm DS1
QN53
02
Transistor,SMT,MOSFET,N-Channel, 60v,115mA,SOT-23 Q01, Q02, Q03, Q04, Q05
RFFS18
02
Resistor, SMT, MF, 22.1ohms, 1%, 1/10W, 0603 R20, R21
RFFS26
02
Resistor, SMT, MF, 100ohms, 1%, 1/10W, 0603 R12, R16
RFFS28
02
Resistor, SMT, MF, 150ohms, 1%, 1/10W, 0603 R03, R05, R06, R14, R18
RFFS50
02
Resistor,SMT,MF,10.0Kohms,1%,1/10W,0603
R02, R04, R07, R08, R09, R10, R11, R13, R15, R17, R19, R22,
R23
SD94
02
Switch, Push-Button, Green/Red, MOM, SPST-NO, PWB S01, S02
SD95
02
Switch, Push-Button, Tactile, SPST-NO, PWB S03
UC107
02
Rotary Encoder, 20PPR, Quadrature, w / MOM Push Bu U01
NAPP15A
01
Directional Coupler Bottom PWB Assy A11
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J01, J02, J03
RT73
02
Resistor, Termination, 50 Ohm, +/- 5%, 60W, Tuned R01
