Nautel VX150 - Page 82

StockCode:
NARF79A
Page 2 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
CT66
02
Capacitor, SMT, Ceramic, 0.1uF 10%, 100V C01, C12
FA79
02
Fuse, SMT, 40A, 72VDC, Very Fast F1
HAC122
02
1 Pin Screw Terminal, Power Tap M3 Surface Mount E1, E2
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J1
LA80C
02
Inductor, 1 turn, rectangular + angled, 0.032" cop L1
LS33
02
Inductor, SMT, 17.5nH, 5%, 4A 3.15mm H x 6.86mm L L2
LS59
02
Inductor, SMT, 22nH, 20%, 40A L3
LS69
02
Inductor, SMT, 150nH, 2%, 1.2A, 4.2mm H x 4.95mm L L4, L5
QAP73
02
Transistor, FET, LDMOS, 65V, Dual, Ruggedized Q1
RAD01
02
Resistor, SMT, MF, 10 Ohms, 1% 1/4W R1
RAD45
02
Resistor, SMT, MF, 47.5K Ohms, 1% 1/4W R5
RFFS94
02
Resistor, SMT, 10 ohms, 1%, 1W, 2512 R4, R6
NAPA41
01
Pre-Amp/IPA Pwb Assy A06
CCFS07
02
Cap,SMT,Ceramic,0.1uF,10%,50V,X7R,0805 C08
CT112
02
Cap, SMT, Elect, Alum Polymer, 100uF, +/- 20%, 25V C06
CT116
02
Capacitor,SMT,6.8pF,+/-0.25pF, 250V,NP0,0805 C12
CT117
02
Capacitor, SMT,33pF,+/-1%,250V, NP0,0805 C03
CT118
02
Capacitor,SMT,51pF,+/-1%,250V,NP0,0805 NP0,0805 C16
CT119
02
Capacitor,SMT,82pF,+/-2%,250V, NP0,0805 C17
CT120
02
Capacitor, SMT,150pF,+/-1%,250V, NP0,0805 C02, C04, C07
CT121
02
Capacitor,SMT,180pF,+/-1%,250V, NP0,0805 C05, C09, C15
CT122
02
Capacitor,SMT, 1000pF, +/-5%, 50V,NP0 C11, C13
CT123
02
Capacitor, SMT, 0.01uF, +/-10%, 50V,BX C10, C14
FA76
02
Fuse, 125 VAC, VDC, 5A, Very fast acting F1
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J1, J2
JU84
02
Conn, Header, Shrouded, 0.050" 16pos, Dual Row, Go J3
LS68
02
Inductor, SMT, 56nH, 2%, 3A, 4.2mm H x 4.95mm L L1
LS70
02
Inductor,SMT,51nH,+/-2%,1A, Ceramic,0805 L7
LS71
02
Inductor,SMT,33nH,+/-2%,0.5A, Ceramic,0805 L6
LS72
02
Inductor,SMT,68nH,+/-2%,0.5A, Ceramic,0805 L5
LS73
02
Inductor,SMT,5nH,+/-2%, 4A,Air L4
LS74
02
Inductor,SMT,33nH,+/-2%, 4.8A,Air L2, L3
