Nautel VX150 - Page 83

StockCode:
NARF79A
Page 3 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
QAP74
02
Transistor,SMT,MOSFET,LDMOS, Single,40V,TO-270-2 Q1
RAD33
02
Resistor, SMT, MF, 4750 Ohms, 1%, 1/4W R2
RAD95
02
Resistor,SMT,1 Ohm,1%, 1/4W,1206 R1
RAD96
02
Resistor,SMT,39.2 Ohms,1%,1/4W,1206 1/4W,1206 R4
RFFS58
02
Resistor, SMT, MF, 47.5Kohms, 1%, 1/10W, 0603 R3
NAPE90/01
01
Exciter, FM, PWB Assy A01
CAP110
02
Capacitor, Double Layer Supercap, 330mF, 5.5V C133
CCFS62
02
Cap, SMT, Ceramic, 10uF, 10%, 25V C013, C106, C220, C234, C465
CCFS69
02
Cap, SMT, Ceramic, 47pF, 5%, 50V, C0G, 0805 C239, C240, C241, C242, C389, C402, C403, C409
CCFS80
02
Cap, SMT, Ceramic, 100uF,20%, 6.3V, 1210 C361, C363, C373, C375
CCFS88
02
Cap, SMT, Ceramic, 4.7uF, 10%, 25V, X5R, 0603
C392, C393, C394, C395, C396, C399, C400, C401, C405,
C406, C407, C408, C410, C411, C412, C413
CCFS89
02
CAP, SMT, Ceramic, 22uF, Low ESR, 25V,+/-20%, 0603 C056, C062
CCFS90
02
CAP, SMT, Ceramic, 10uF, Low ESR, 25V,+/-20%, 0603 C044, C046, C048, C049, C076, C084
CCJ01
02
Cap,SMT,Ceramic,1000pF,10%, 50V,X7R,0402 C014, C022, C027, C031, C093, C094, C460
CCJ02
02
Cap,SMT,Ceramic,0.01uF,10%, 50V,X7R,0402
C004, C007, C016, C028, C032, C039, C041, C052, C053,
C057, C058, C059, C065, C066, C069, C070,, C074, C075,
C077, C078, C079, C081, C082, C083, C085, C087, C130,
C136, C144, C149, C152, C156,, C159, C164, C165, C167,
C169, C175, C176, C178, C179, C182, C183, C191, C192,
C193, C194, C210,, C211, C245, C247, C250, C251, C253,
C254, C255, C257, C258, C262, C266, C267, C268, C269,
C270,, C271, C279, C280, C282, C283, C284, C285, C287,
C293, C296, C297, C298, C299, C300, C302, C303,, C310,
C311, C312, C314, C319, C324, C326, C333, C334, C335,
C337, C340, C342, C343, C352, C356,, C357, C359, C360,
C364, C370, C380, C384, C390, C417, C418, C419, C420,
C421, C422, C424, C425,, C426, C427, C440, C441, C442,
C443, C467
