Nautel VX150 - Page 89

StockCode:
NARF79A
Page 9 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
UW194
02
IC SMT FPGA Cyclone 77K cells 1.1V 484-Pin FBGA U31
UW195
02
IC SMT DAC Dual-Channel, 16- Bit, 1.25 GSPS U11
UW203
02
SHARC+ Dual Core DSP with ARM, 450MHz, 529cspBGA U47
UW204
02
IC, SMT, SPI Flash, 128Mbit, 3V, 8-SOIC U52
UW208
02
Resistor, SMT, Network, 33 Ohm, Quad, 0804
U37, U38, U39, U40, U41, U42, U43, U44, U45, U53, U54, U55,
U56, U57, U58, U69, U70, U71, U72,, U73, U74, U75, U76, U77
U78, U79
UW226
02
Attenuator, SMT, 1dB , 50 Ohm, 0.5W, DC to 8GHz U01
UW64
02
IC,SMT,DAC,16 Bit Serial,MSOP-9 U27
UW76
02
Attenuator,SMT,12dB,50 ohm, 0.5W,DC to 8 GHz U03
UW90
02
IC,SMT,Quad 2 TO 1 DATA Sel/ Mux 3 States Output,3 U23, U24, U26, U33, U61, U64, U65, U66, U67
UX188
02
IC SMT CLK SYNTH/JITTER CLEANE R 48QFN U22
UX192
02
IC, SMT, Phy, Ethernet, 10/100 , 3.3V, 1 Port, LQF U35
UX193
02
IC, SMT, USB 2.0 Hub, 4-Port, HTQFP-64 U36
UX195
02
IC, SMT, Optocoupler, Quad, 3750Vrms ISO, SO16 U12, U17, U28
UX206
02
IC, SMT, Memory, 2Gb DDR3L SDRAM, 128Mx16, 96FBGA U59, U60
UX208
02
IC, SMT, ADC, DUAL, 12BIT, 125MSPS, 64VQFN U05
UX209
02
IC, SMT Current Limiting Power Distribution Switch U81
UX64
02
IC,SMT,Power Supervisor,Dual I/P,33/1.5V,MSOP U51
UX83
02
IC,SMT,2.5V Reference,0.1%,SOT -23-6 U34
XFPS10
02
Crystal,SMT,Fund,ParRes,32.768 kHz, 20ppm, 12.5pF, Y03
XFPS16
02
Crystal, SMT, Fundamental, 24MHz, 18pF, 40O Y02
NAPF16A
01
PA LPF PWB Assy A09
CT106
02
Capacitor,SMT,Porcelain,1.5pF, 1500V,+/-0.1pF C06
CT107
02
Capacitor,SMT,Porcelain,1.8pF, 1500V,+/-0.1pF C10
CT108
02
Capacitor,SMT,Porcelain,3.3pF, 1500V,+/-0.1pF C08
CT109
02
Capacitor,SMT,Porcelain,5.6pF, 1500V,+/-0.1pF C07, C09
HAC122
02
1 Pin Screw Terminal, Power Tap M3 Surface Mount E01
LA77G
02
Inductor, SMT, Air Core, 2.5 turn, 10 AWG TCW, 0.5 L01
LA78G
02
Inductor, SMT, Air Core, 2.5 turn, 10 AWG TCW, 0.5 L02
LA79G
02
Inductor, SMT, Air Core, 2.5 turn, 10 AWG TCW, 0.4 L03
