Nautel VX150 - Page 90

StockCode:
NARF79A
Page 10 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
NAPI187A
01
System Interface PWB Assy A03
CCJ01
02
Cap,SMT,Ceramic,1000pF,10%, 50V,X7R,0402 C02, C04, C11, C12, C14, C15, C53, C81, C82, C86
CCJ02
02
Cap,SMT,Ceramic,0.01uF,10%, 50V,X7R,0402 C19, C22, C47, C65, C83, C84
CCJ03
02
Cap,SMT,Ceramic,0.1uF,10%, 50V,X7R,0402
C01, C03, C05, C13, C16, C17, C18, C20, C21, C24, C25, C26,
C27, C28, C29, C30,, C31, C32, C37, C38, C40, C41, C42, C43
C44, C45, C46, C48, C50, C51, C54, C55, C56, C57, C58, C59
,
C61, C63, C64, C66, C68, C69, C71, C72, C74, C77, C78, C79,
C80
CCJ04
02
Cap,SMT,Ceramic,1uF,10%, 25V,X5R,0402 C08, C09, C23, C39, C73, C85
CCJ06
02
Cap,SMT,Ceramic,4.7uF,10%, 25V,X7R,0805 C52, C60, C62, C75
CCJ10
02
Cap,SMT,Ceramic,18pF,1%, 50V,C0G,0402 C67
CCJ18
02
Cap,SMT,Ceramic,22uF,20%, 25V,X5R,0805 C70, C76
CCJ20
02
Cap,SMT,Ceramic,15pF,1%, 50V,C0G,0402 C33, C35
CT112
02
Cap, SMT, Elect, Alum Polymer, 100uF, +/- 20%, 25V C06, C07, C10
CT65
02
Cap, SMT, Ceramic, 6.8pF, 50V, +/-0.25pF, 1206 C49
HAJ66
02
Terminal , S M T, Test Poi n t , P W B TP03, TP14
JF47
02
Conn, Header,Square Post,Gold, Dual,40-pin J12
JQ16
02
Conn, Header, SIP, 12 Pin Breakaway, 10 Ctr J11
JR77
02
Terminal Block, 2 Pos, 300V, 13A, 28-14AWG, Spring TB02
JR89
02
Terminal Block, 4 Pos, 300V, 26 - 20AWG, Spring C TB01
JT188
02
Conn, Jack, MCX, 50Ohm, Gold, Vert, SMT J05, J06, J09
JU131
02
Conn, Header, Shrouded, 4-pos, 3.00mm, Dual Row, G J01, J02
JU84
02
Conn, Header, Shrouded, 0.050" 16pos, Dual Row, Go J07
JU91
02
Conn, Header, Shrouded, 0.050" 10pos, Dual Row, Go J04, J10
JU96
02
Conn, Header, Shrouded, 0.050" 20pos, Dual Row, Go J03, J08
LCFS01
02
Inductor, SMT, Choke, 600ohms, 2A, 0805 L05, L06, L10, L11
LCFS02
02
Inductor, SMT, Choke, 2000 ohm s, 80mA, 0805 L08, L15, L16
LS18
02
Inductor,SMT.2.2uH,600ma,1210 L12
LS34
02
Inductor, SMT, 28nH, 2%, 4A 3.15mm H x 6.86mm L L09
LS45
02
Inductor, SMT, Shielded, 33uH, 3.3A RMS L03, L04
LS60
02
Inductor, SMT, 22uH, 4A RMS, Shielded, Pwr L13
LS61
02
Inductor, SMT, 9.5nH, 480mArms, 5%, 0402 L17
QDLS02
02
Diode, SMT, LED, Yellow/Green, (570nm), 0603 DS01
QDSS01
02
Diode, SMT, Schottky, 30V, 0.2A, SOD-323 CR01, CR04, CR05
QN53
02
Transistor,SMT,MOSFET,N-Channel, 60v,115mA,SOT-23 Q01, Q02, Q03, Q04, Q05
