Nautel VX150 - Page 91

StockCode:
NARF79A
Page 11 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
QR82
02
Diode, SMT, TVS, Vw 5V, Vb 6V Vc 10.8V, SOT-143 CR02, CR03
RAD15
02
Resistor, SMT, MF, 150 Ohms, 1% 1/4W R39, R40
RAD38
02
Resistor, SMT, MF, 12.1K Ohms, 1% 1/4W R34
RAD93
02
Resistor, SMT, 0.01 ohms, 1%, 1/4W, 1206 R80
RAF24
02
Resistor SMT MF 68.1 Ohm 1% 1/16W 0402 R98
RAF27
02
Resistor SMT MF 121 Ohm 1% 1/16W 0402
R01, R03, R09, R12, R17, R20, R23, R26, R35, R38, R41, R53,
R54, R61, R62, R63, R71, R72, R74,, R75, R76, R78, R84, R85
R86, R87, R91, R92, R93, R94
RAF34
02
Resistor SMT MF 475 Ohm 1% 1/16W 0402 R83, R88, R90, R95
RAF38
02
Resistor SMT MF 1000 Ohm 1% 1/16W 0402 R33
RAF42
02
Resistor SMT MF 2210 Ohm 1% 1/16W 0402 R02, R04, R43, R44, R46, R56, R57, R64, R68
RAF44
02
Resistor SMT MF 3320 Ohm 1% 1/16W 0402 R06, R08, R10, R11, R36, R52
RAF50
02
Resistor SMT MF 10.0K Ohm 1% 1/16W 0402
R05, R07, R13, R14, R15, R16, R29, R30, R31, R32, R37, R42,
R47, R50, R51, R55, R65, R69, R79,, R81, R82, R89, R96
RAF54
02
Resistor SMT MF 22.1K Ohm 1% 1/16W 0402
R21, R22, R27, R28, R45, R48, R49, R58, R59, R60, R67, R70,
R73
RAF56
02
Resistor SMT MF 33.2K Ohm 1% 1/16W 0402 R18, R24
RAF62
02
Resistor SMT MF 100K Ohm 1% 1/16W 0402 R19, R25, R66, R77
RAF83
02
Resistor SMT MF 499 Ohm 1% 1/16W 0402 R97
RFFS04
02
Resistor, SMT, MF, 1.50ohms, 1%, 1/10W, 0603 R99
RT50
02
Resistor,SMT,MF,0.0 ohms, Jumper,0805 L01, L02, L07, L14
UDTS04
02
IC,SMT,RS-485 Transceiver,3.3V ,SO-8 U07, U08
UDTS05
02
IC, SMT, RS-232 Transceiver, 3.3V, SO-16 U04
ULAS01
02
IC,SMT,Opamp,Quad,Single Supply,SOIC-14 U01
UT157
02
IC, SMT, DC-DC Conv, Buck, Adj, 2A, 4.5-28Vin, SOT U06
UT158
02
IC, SMT, Amp, Current Sense, Precision, 50V/V, SOT U05
UW207
02
Attenuator, SMT, 20dB, 50 ohm, 0.5W, DC to 8 GHz U09
UX161
02
IC, SMT, Micro, 128K, 8K SRAM, 3.3V, TQFP-100 U02
UX191
02
IC, SMT, RMS RF Power detector , 3.3V, 40MHz-10GHz U10
UX83
02
IC,SMT,2.5V Reference,0.1%,SOT -23-6 U03
XFPS14
02
Crystal,SMT,Fund,32.768kHz, 10ppm,12.5pF,50kOhm,-4 Y01
NAPI188
01
Power Supply Interface PWB Assy - 3.5kW A04
CCFS09
02
Cap,SMT,Ceramic,0.47uF,10%,25V,X7R,0805 C02
