Nautel VX150 - Page 93

StockCode:
NARF79A
Page 13 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
CCJ03
02
Cap,SMT,Ceramic,0.1uF,10%, 50V,X7R,0402
C003, C007, C008, C010, C015, C016, C017, C018, C019,
C020, C026, C031, C032, C034, C038, C039,, C051, C053,
C056, C062, C065, C067, C082, C083, C085, C087, C088,
C091, C095, C098, C100,, C104, C108, C111, C113, C115,
C121, C124, C127, C131
CCJ04
02
Cap,SMT,Ceramic,1uF,10%, 25V,X5R,0402
C004, C009, C012, C014, C021, C024, C025, C027, C037,
C041, C046, C050, C055, C063, C068, C069,, C073, C078,
C081, C086, C092, C094, C101, C102, C103, C107, C112,
C116, C119, C120
CCJ05
02
Cap,SMT,Ceramic,10uF,10%, 25V,X5R,0805
C033, C040, C054, C059, C070, C071, C072, C079, C090,
C132
CCJ07
02
Cap,SMT,Ceramic,100pF,1%, 50V,C0G,0402 C048, C049, C057, C080, C089, C110, C128
CCJ08
02
Cap,SMT,Ceramic,2.2uF,10%, 25V,X5R,0402 C011, C035, C043, C060, C097
CCJ10
02
Cap,SMT,Ceramic,18pF,1%, 50V,C0G,0402 C093, C105, C114, C125
CCJ13
02
Cap,SMT,Ceramic,3300pF,10%, 50V,X7R,0402 C077
CCJ19
02
Cap,SMT,Ceramic,470pF,1%, 50V,C0G,0402 C042, C076, C122
CCJ20
02
Cap,SMT,Ceramic,15pF,1%, 50V,C0G,0402 C099
CCJ26
02
Cap,SMT,Ceramic,220pF,1%,50V, COG/NPO,0402 C052, C109
CCJ28
02
Cap,SMT,Ceramic,39pF,1%,50V, NPO/COG,0402 C075, C123
HAJ66
02
Terminal , S M T, Test Poi n t , P W B TP01, TP14
JT204
02
Conn, BNC, Dual Stacked, Isolated J01
JT61
02
Conn, BNC, Recept, 50ohm,Insul , Rt Angle J02
JT87
02
Conn,3-pin,PWB Mount, Fem, XLR J03, J04
JU85
02
Conn, Header, Shrouded, 0.050" 30pos, Dual Row, Go J05
LA72
02
Bead, Ferrite, SMT, 120 Ohm at 100MHz, 1.3A, 0402 L02
LS56
02
Inductor, SMT, 3.3uH, 5.6A,RMS L01, L03, L04
QDDS02
02
Diode, SMT, Schottky, 40V, 1A, SMA CR04
QDSS01
02
Diode, SMT, Schottky, 30V, 0.2A, SOD-323 CR03
QDZS11
02
Diode, SMT, Zener, 5.6V, 1.5W, SMA, 403D CR01, CR02, CR05, CR06
RAD23
02
Resistor, SMT, MF, 681 Ohms, 1% 1/4W R011, R052
RAF01
02
Resistor SMT MF 0.0 Ohm Jumper 0402 R034, R095, R099, R100, R123
RAF18
02
Resistor SMT MF 22.1 Ohm 1% 1/16W 0402 R090, R103, R144, R145
RAF26
02
Resistor SMT MF 100 Ohm 1% 1/16W 0402
R003, R018, R037, R038, R048, R069, R082, R097, R113,
R131, R153
