Nautel VX150 - Page 94

StockCode:
NARF79A
Page 14 of 51
Description
:
Final Assy, VX1,
Component Lvl, StockCode Reference DesignationDescription
RAF38
02
Resistor SMT MF 1000 Ohm 1% 1/16W 0402
R007, R008, R009, R014, R015, R016, R031, R032, R044,
R045, R046, R060, R061, R062, R109, R110,, R117, R125,
R127, R128, R129, R136, R137, R149, R150
RAF50
02
Resistor SMT MF 10.0K Ohm 1% 1/16W 0402
R004, R005, R012, R019, R023, R025, R026, R027, R033,
R035, R039, R041, R042, R050, R051, R053,, R056, R057,
R058, R066, R070, R073, R074, R075, R080, R085, R086,
R089, R093, R096, R098, R101,, R102, R104, R105, R106,
R107, R108, R114, R119, R126, R134, R135, R146, R147,
R148
RAF52
02
Resistor SMT MF 15.0K Ohm 1% 1/16W 0402 R021, R029, R079, R118
RAF56
02
Resistor SMT MF 33.2K Ohm 1% 1/16W 0402 R055
RAF57
02
Resistor SMT MF 39.2K Ohm 1% 1/16W 0402
R006, R013, R020, R043, R059, R072, R088, R111, R116,
R141, R151
RAF59
02
Resistor SMT MF 56.2K Ohm 1% 1/16W 0402 R024, R028, R049, R054, R094
RAF63
02
Resistor SMT MF 121K Ohm 1% 1/16W 0402 R071
RAF66
02
Resistor SMT MF 221K Ohm 1% 1/16W 0402 R087, R120
RAF74
02
Resistor SMT MF 1.00M Ohm 1% 1/16W 0402 R001, R030
RAF87
02
Resistor SMT MF 3740 Ohm 1% 1/16W 0402 R010, R017, R047, R063
RAF93
02
Resistor SMT MF 7.15K Ohm 1% 1/16W 0402 R077, R083, R132, R139
RAF94
02
Resistor SMT MF 3.57K Ohm 1% 1/16W 0402 R078, R133
RAF95
02
Resistor SMT MF 4.12K Ohm 1% 1/16W 0402 R084, R091, R140, R142
RAF96
02
Resistor SMT MF 2.10K Ohm 1% 1/16W 0402 R092, R143
US12
02
IC, SMT, Rectifier, Bridge, 400V, 0.5A, SOIC-4 U02, U08, U21, U26
US58
02
IC, SMT, 24Bit Audio Codec, SPI, I2C, TSSOP28 U06
US59
02
IC, SMT, 10-Bit A/D Converter, 4Ch, 200KSPS, 10-VS U03
US60
02
IC, SMT, ADC 16 Bit, 2Ch, 750KSPS, 16-WQFN U17
UT170
02
IC, SMT, Adj. DC to DC Inverting Reg, 2.4A, 16-LFC U20
UT171
02
IC, SMT, Op AMP, Dual, Low Noise, Bipol Supply, 8- U01, U04, U09, U13, U15, U18, U19, U23
UT172
02
IC, SMT, Precision Diff Amp, 8-MSOP U05, U10, U16, U25
UT178
02
IC, SMT, Rail to Rail Dual Op-amp, Wide BW, SOIC8 U14, U24
UX66
02
IC,SMT,Linear Regulator,150mA Adj.,MSOP-8 U07, U11, U12
UX83
02
IC,SMT,2.5V Reference,0.1%,SOT -23-6 U22
NAPI193
01
Front Panel User Interface Pwb Assy A05
CCFS04
02
Cap,SMT,Ceramic,0.01uF,10%,50V,X7R,0603 C02, C03
