Nautilus E916 User Manual
4
of 1
of 1 rating
72 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
1
9
Naut
ilus
® Comm
eri
c
al Ser
ies Ellipti
c
al Ser
v
ic
e Manual
Main P
ower
Wir
ing Diagram
EV916 Elliptical Power Electronics and
Alternator Wiring Diagram
Notes:
Place field diode assembly (21204) between field and ground
terminals on the alternator (22661).
18
20
Table of Contents
Default Chapter
3
Table of Contents
3
Important Safety Information
5
Product Specifications
6
EV916 Elliptical Trainer
6
E916 Elliptical Trainer
7
Console Codes
9
Overview
11
Defaults
11
Customize
11
Machine Status
12
Diagnostics
13
Maintenance Logs
13
Maintenance Logs
14
Reset Maintenance Hours
14
Error Log
14
Machine Configuration
16
Wiring Schematics
17
EV916 Top Level Wiring Diagram
18
EV916 Power and Alternator Wiring Diagram
19
E916 Console Heart Rate Wiring Diagram
20
E916 Main Power Wiring Diagram
21
Assembly Illustrations
23
Service Parts List - EV916
25
Cable Connections - EV916
31
Assembly Drawings Overview - EV916
33
Cam Covers (Pods) and Front Knuckle Covers
33
Swing Arm / Foot Link Assembly Junction
34
Front Mast Assembly / Main Frame Junction
34
Drive Train Cover Assembly
35
Drive Train Assembly W/ Main Power Assembly
35
Crank Cover and Crank Assembly
36
Rear Drive Assembly
37
Alternator Assembly
38
Foot Link Assembly (Left)
38
Foot Link Assembly (Right)
39
Dependency Cover (Cupholder) Assembly
39
Swing Arm Assembly
40
Dependency Link Assembly
41
Dynamic (Upper Body) Handles Assembly
42
Fixed Handle (T-Bar) Assembly
42
Console Mount
43
Service Parts List - E916
44
Cable Connections - E916
53
Assembly Drawings Overview - E916
54
Cam Covers (Pods) and Front Knuckle Covers
54
Swing Arm / Foot Link Assembly Junction
55
Drive Train Cover Assembly
56
Front Mast Assembly / Main Frame Junction
56
Crank Arm Assembly
57
Crank Cover and Drive Train Assembly
57
Eccentric Crank Arm Assembly (Detail)
58
Rear Drive Assembly
59
Alternator Assembly
60
Connecting Arm Assembly
60
Foot Link Assembly (Left)
61
Foot Link Assembly (Right)
61
Foot Linkage Assembly (Left)
61
Foot Linkage Assembly (Right)
61
Swing Arm Assembly
62
Swing Arm Cover and Cupholder
62
Dynamic Handles and Polar Sensor
63
Dynamic (Upper Body) Handles and Grips
64
Fixed (T-Bar) Handle Assembly
64
Console Support
65
Appendixes
67
Required Tools
68
International Power Plug Configurations
68
Warranty Information
69
Contact Numbers
70
