Nautilus® Commerical Series Elliptical Service Manual
Service Parts List - EV916
Assembly Parts List - EV916
Part number information in the following table is meant to help you identify the parts in the drawings for ordering
replacement parts. Call an authorized Nautilus representative at 1-800-NAUTILUS (624-8458) to order replacement
parts and get assistance with your specific replacement or service requirements. Items with no warranty code or
part number are replaceable only as part of a higher-level assembly.
WARRANTY NOTES (FOR UNITS IN USA ONLY):
1 - Part covered under standard 3-year parts warranty for replacement.
2
- Part covered under standard 1-year wear item warranty for replacement.
3
- Part covered under standard 15-year frame warranty for replacement.
Table 5-1. Part Identifier List – EV916 Elliptical
SRVC#
WRNTY-
CODE
PART NO./ LEVEL
DESCRIPTION
1 2 3 4
SM25067
1
25067 ASSY.,BC-1, POWER SUPPLY
NA 14029 PINS,CPC
NA 21179 CONNECTOR,CPC 11-4 PLUG REVRSE
NA 21184 CONNECTOR, BACKSHELL
NA 21757 DECAL,WARNING, BATTERY CHARGER
NA 25066 POWER SUPPLY, BC-1,1A WALL PACK
SM27857
2
27857 COMMERCIAL PRODUCT WARRANTY
NA
2
40334 MANUAL, OWNERS, CD, EV916/E916
NA
2
40335 MANUAL, OWNERS, EV916/E916
NA
2
40388 MANUAL, ASSY, E916/EV916
SM12212
1
12212 KEY, .250 SQUARE X .75 LONG
SM13584
1
13584 CABLE,ALTERNATOR,3300CE/3900RC
SM22242
1
22242 SCREW,.375-16X.75,HEX HD CAP
SM22030
1
22030 WASHER, 3/8 USS FLAT
SM22046
1
22046 WASHER,FLAT,.562x1.375 x .109
SM22663
1
22663 SCREW,#6 X .50 PHIL,TYPE T
SM23081
1
23081 SCREW,.500-13X4.00,HEX HD CAP
SM23729
1
23729 WASHER, 3/8 SPLIT LOCK
SM40305
1
40305 ASSEMBLY, CRANK ARM, 5300
SM22036 22036 NUT,.250-20,NYLON INSERT
SM22047 22047 WASHER,FLAT,1/4 ID X 5/8 OD
NA 40303 WELDMENT, CRANK ARM ASSEMBLY
SM40562 40562 SCREW,5/16-18 X 1.50 SHC W/NYL
SM40697 40697 SCREW,1/4-20 X 3.50,HEX HD CAP
SM40767 40767 BRACE,CRANK COVER
