Nautilus E916 - Page 26

26
SRVC#
WRNTY-
CODE
PART NO./ LEVEL DESCRIPTION
1 2 3 4
SM40306 40306 ASSEMBLY, REAR DRIVE, VSL
SM12221
1
12221 INTERMEDIATE PULLEY, MOLDED
SM12419
1
12419 KEY, .250 SQ X 2.50 LONG
SM20205
1
20205 ALTERNATOR, PRESTOLITE, 1992
SM21445
1
21445 ASSY.,SPEED SENSOR,CLIM.SYS,CL
SM21448
1
21448 SCREW,.375-16 x 4.50 HEX HD CP
SM21774
1
21774 PIN,HITCH
SM21778
1
21778 NUT, FLANGE (ALT-FLYWHEEL)
SM22029
1
22029 NUT,.375-16,NYLON INSERT
SM22030
1
22030 WASHER, 3/8 USS FLAT
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM22070
1
22070 WASHER,.312 SPLIT LOCK
SM22093
1
22093 SCREW,.312-18X.75,HEX HD CAP
SM22116
1
22116 SCREW,.250-20X2.50,HEX HD CAP
SM22191
1
22191 WASHER,SHOULDER,.38 I.D.
SM22214
1
22214 WASHER, FLAT, .312 SAE
SM22326
1
22326
PIN,CLEVIS
SM22516
1
22516 CLAMP, CABLE,.75 DIA
SM22517
1
22517
DISK, SPEED SENSOR, 4400 CL
SM22878
1
22878 SCREW,SET,SOCKET,.250-28 X .38
SM22883
1
22883 SCREW, SET,SOCKET,3/8-16 X .38
SM22937
1
22937 SCREW,.375-16 X 3.50,HX HD CAP
SM23322
1
23322 BEARING, BALL 17MM X 40MM
SM23729
1
23729 WASHER, 3/8 SPLIT LOCK
SM24640
1
24640 SCREW,.375-16 X 1.75 HX HD CAP
SM25978
1
25978 WHEEL, 3” DIA.
SM27654
1
27654 LEVELING PAD (.500-13UNC-2A X 1.88 BASE)
SM40301
3
40301
WELDMENT, REAR FRAME, STRIDEMASTER
SM40530
1
40530 PULLEY, DRIVE, MACHINED
SM40598
3
40598 WELDMENT, ALTERNATOR, TENSIONER
SM40605
3
40605 WELDMENT, INTERMED PULLEY TENSIONER
SM40608
1
40608 SHAFT, INTERMEDIATE PULLEY
SM40609
1
40609 SPACER, INTERMEDIATE SHAFT, LEFT
SM40610
1
40610 SPACER, INTERMEDIATE SHAFT, RIGHT
SM40611
1
40611 SHAFT, CRANK
SM40618
1
40618 BELT, POLY-V,61”,J, 16 RIB
SM40619
1
40619 BELT, POLY-V,38”,J, 8 RIB
Service Parts List - EV916
