Nautilus® Commerical Series Elliptical Service Manual
SRVC#
WRNTY-
CODE
PART NO./ LEVEL DESCRIPTION
1 2 3 4
SM40734
1
40734
BEARING,1” PILLOW BLOCK,NO COL
SM40329
1
40329 FLYWHEEL, CAST, 5300
SM40307 40307 ASSEMBLY, FRONT MAST, VSL
SM12497
2
12497 CONTACT PLATE, CHR
SM12506
2
12506 ADHESIVE TRANSFER TAPE, 5 MIL
SM13582
1
13582 WASHER,FLAT,#4 TYPEB,.125x.250
SM21135
1
21135 LOOM, FLEXIBLE .350 I.D.
NA
1
21607 TAPE,DOUBLE SIDED FOAM
SM22027
1
22027 WASHER,.250 SPLIT LOCK
SM22028
1
22028 SCREW,.250-20X.63,HEX HD CAP
SM22043
1
22043 SCREW,.500-13X2.00,HEX HD CAP
SM22046
1
22046 WASHER,FLAT,.562x1.375 x .109
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
NA
1
22603 RIVNUT, #10-32 UNF, .020-.130 GRIP
SM23092
1
23092 SCREW,.500-13X2.50,HEX HD CAP
SM24049
1
24049
SNAP RING, EXTERNAL, 1.50 DIA.
SM27557
1
27557 RETAINING RING 5100-98
SM27654
1
27654 LEVELING PAD (.500-13UNC-2A X 1.88 BASE)
SM40302
3
40302 WELDMENT, CONSOLE MOUNT
SM40312
3
40312 WELDMENT, SWING ARM, LEFT
SM40313
3
40313 WELDMENT, SWING ARM, RIGHT
SM40315
3
40315 WELDMENT, RIGHT MOVING HANDLEBAR
SM40316
3
40316 WELDMENT, LEFT MOVING HANDLEBAR
SM40317
3
40317 LINK, DEPENDENCY, CAST
SM40321
3
40321 WELDMENT, TURNBUCKLE
SM40396
1
40396 SPACER, DEPENDENCY ROD-END
SM40400
1
40400
PCBA, STRIDE SENSOR
SM40401
1
40401 BRACKET, STRIDE SENSOR, SIGNAL
SM40464
2
40464 DECAL, CONSOLE BACK
SM40551
2
40551
COVER, ERGOBAR, FRONT
SM40552
2
40552
COVER, ERGOBAR, BACK
SM40564
1
40564
BEARING,IGUS JFI-2428-16
SM40576
2
40576
HOUSING, CHR, FIXED, TOP
SM40577
2
40577
HOUSING, CHR, FIXED, BOTTOM
SM40578
2
40578 KEYPANEL,HANDRAIL,RIGHT,5100
SM40579
2
40579 KEYPANEL,HANDRAIL,LEFT,5100
SM40639
1
40639 SCREW,6-32 X .438 LG SHC
