Nautilus E916 User Manual

44
Service Parts List - E916
Part number information in the following table is meant to help you identify the parts in the drawings for ordering
replacement parts. Call an authorized Nautilus
®
representative at 1-800-NAUTILUS (624-8458) to order replacement parts
and get assistance with your specific replacement or service requirements. Items with no warranty code or part number are
replaceable only as part of a higher-level assembly only.
WARRANTY NOTES (FOR UNITS IN USA ONLY):
1 - Part covered under standard 3-year parts warranty for replacement.
2
- Part covered under standard 1-year wear item warranty for replacement.
3
- Part covered under standard 15-year frame warranty for replacement.
Table 5-2. Part Identifier List – E916 Elliptical
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
SM25067
2
25067 ASSY.,BC-1, POWER SUPPLY
NA 14029 PINS,CPC
NA 21179 CONNECTOR,CPC 11-4 PLUG REVRSE
NA 21184 CONNECTOR, BACKSHELL
NA 21757 DECAL,WARNING,BATTERY CHARGER
NA 25066 POWER SUPPLY,BC-1,1A WALL PACK
SM27857
2
27857 COMMERCIAL PRODUCT WARRANTY
NA
2
40334 MANUAL, OWNERS, CD, EV916/E916
NA
2
40335 MANUAL, OWNERS, EV916/E916
NA
2
40388 MANUAL, ASSY, E916/EV916
SM12212
2
12212 KEY,.250 SQUARE X .750 LONG
SM12419
2
12419 KEY, .250 SQ X 2.50 LONG
SM22030
2
22030 WASHER, 3/8 USS FLAT
SM22042
2
22042 NUT,.500-13,NYLON INSERT
SM22046
2
22046 WASHER,FLAT,.562x1.375 x .109
SM22242
2
22242 SCREW,.375-16X.75,HEX HD CAP
SM23729
2
23729 WASHER, 3/8 SPLIT LOCK
SM26669
2
26669 SCREW,.500-13x4.50,HEX HD CAP
SM29062
2
29062 SCREW,1/4-28X 5/8 SOCKET HD CP
SM40358
2
40358 SHAFT, SWING ARM PIVOT
SM40381
1
40381
COVER, CRANK, STEEL
SM40426
2
40426 COVER, KNUCKLE, FRONT LEFT
SM40427
2
40427 COVER, KNUCKLE, FRONT RIGHT
SM40436
2
40436 DECAL,ID,RIGHT
SM40437
2
40437 DECAL,ID,LEFT
Service Parts List - E916
