Nautilus E916 - Page 45

45
Nautilus® Commerical Series Elliptical Service Manual
SRVC#
WRNTY-
CODE
PART NO. / LEVEL DESCRIPTION
-1 -2 -3 -4
SM40525
2
40525
COVER,DRIVETRAIN,RIGHT
SM40526
2
40526
COVER,DRIVETRAIN,LEFT
SM40527
2
40527
COVER,DRIVTRAIN,TOP
SM40556
2
40556 COVER,FRONT,BOTTOM,LEFT
SM40558
2
40558 COVER,FRONT,BOTTOM,RIGHT
SM40592
2
40592 COVER,POD,TOP,LEFT
SM40593
2
40593 COVER,POD,BOTTOM,LEFT
SM40596
2
40596 COVER,POD,TOP,RIGHT
SM40597
2
40597 COVER,POD,BOTTOM,RIGHT
SM40616
1
40616 SPACER,CRANK SHAFT
SM40654
1
40654 SCREW,10-32X.75,PANHD W/LK WAS
SM40667
1
40667 SCREW, 5/16-18X.75,BH CAP,SS
SM40668
1
40668 WASHER,FLAT,11/32IDX3/4ODX.050
SM40669
1
40669 WASHER,SPRING LOCK,5/16,SS
SM40670
1
40670 SCREW,1/4-20X.75,PAN HD,W/LOCK
SM40751
1
40751 RING,RETAINING,EXTERNAL,15MM
SM40783
1
40783 ASSEMBLY,CRANK ARM,RIGHT,V2
SM12212 12212 KEY,.250 SQUARE X .750 LONG
SM22036 22036 NUT,.250-20,NYLON INSERT
SM22047 22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM27557 27557 RETAINING RING 5100-98
SM40562 40562 SCREW,5/16-18 X 1.50 SHC W/NYL
SM40594 40594 BEARING, BALL, 25 X 47 X 12
SM40647 40647 WELDMENT,PIVOT,MISALIGNMENT
NA 40595 HOUSING,BEARING,PIVOT,MISALIGN
NA 40648 STUD,PIVOT MISALIGNMENT
NA 40697 SCREW,1/4-20 X 3.50,HEX HD CAP
NA 40767 BRACE,CRANK COVER,V2
NA 40779 SPACER,ECCENTRIC SHAFT
NA 40780 ARM,CRANK,V3
NA 40930 CASTING,ECCENTRIC,CRANK ARM
SM40784
1
40784 ASSEMBLY,CRANK ARM,LEFT,V2
SM12212 12212 KEY,.250 SQUARE X .750 LONG
SM22036 22036 NUT,.250-20,NYLON INSERT
SM22047 22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM27557 27557 RETAINING RING 5100-98
SM40562 40562 SCREW,5/16-18 X 1.50 SHC W/NYL
Service Parts List - E916
