28
SRVC#
WRNTY-
CODE
PART NO./ LEVEL DESCRIPTION
1 2 3 4
SM40642
2
40642 CONTACT PLATE, CHR, LONG
SM40643
2
40643
HOUSING, CHR, DYNAMIC, FRONT
SM40644
2
40644
HOUSING, CHR, DYNAMIC, REAR
SM40651
1
40651 WASHER,NYLATRON,1.505 X 2.250
SM40652
1
40652 WASHER,WAVE,1.560 X 1.8750 X .
SM40654
1
40654 SCREW,10-32X.75,PANHD W/LK WASHER
SM40655
1
40655 NUT,LOCK,CONICAL TOP,1/2-13
SM40679
1
40679 CABLE,ASSY,T-BAR GRIP TO CONSOLE
SM40680
1
40680 ASSY,CABLE,ELLIPTICAL SWINGARM
SM40692
1
40692 PCB ASSEMBLY,ELLIPT SWINGARM
SM40696
1
40696 CABLE,C41 SWINGARM INTERMEDIATE
SM40760
1
40760
LABEL,SWING ARM,WIRE,RH
SM40761
1
40761
LABEL,SWING ARM,WIRE,LH
SM40776
2
40776 ADHESIVE,TRANSFER TAPE,25 MIL
SM40777
1
40777 SCREW,6-32X1.25 LG HEX SHC
SM41269
1
41269 GROMMET, 2870, 7/8” ID
SM40318 40318 ASSEMBLY, FOOT LINK, RIGHT
SM22027
1
22027 WASHER,.250 SPLIT LOCK
SM22028
1
22028 SCREW,.250-20X.63,HEX HD CAP
SM22032
1
22032 NUT,5/16-18 NC NYLON INSRT HEX
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
NA
3
40309 WELDMENT, MAIN FOOTLINK RIGHT
SM40424
2
40424 HOUSING, FOOT PAD, RIGHT
SM40434
2
40434 FOOT PAD, RIGHT
SM40443
1
40443 SCREW, 10-32 X 1.00 LG, OVAL HD PH, SS
SM40450
1
40450 RUBBER, BRAKE
SM40457
1
40457
DIA. 3/8 X 1/2 LG SHOULDER; 5/16 - 18 UNC X
1/2 LG THREADS; SOCKET HEAD
SM40460
1
40460 BRKT, BRAKE RUBBER MNTG, LEFT, OUTSIDE
SM40461
1
40461 BRKT, BRAKE RUBBER MNTG, LEFT, INSIDE
SM40319 40319 ASSEMBLY, FOOT LINK, LEFT
SM22032
1
22032 NUT,5/16-18 NC NYLON INSRT HEX
SM22027
1
22027 WASHER,.250 SPLIT LOCK
SM22028
1
22028 SCREW,.250-20X.63,HEX HD CAP
SM22047
1
22047 WASHER,FLAT,1/4 ID X 5/8 OD
SM22120
1
22120 WASHER, #6 INTERNAL TOOTH LOCK
NA
2
40310 WELDMENT, MAIN FOOTLINK LEFT
Service Parts List - EV916
