29
Nautilus® Commerical Series Elliptical Service Manual
SRVC#
WRNTY-
CODE
PART NO./ LEVEL DESCRIPTION
1 2 3 4
SM40425
2
40425 HOUSING, FOOR PAD, LEFT
SM40435
2
40435 FOOT PAD, LEFT
SM40443
1
40443 SCREW, 10-32 X 1.00 LG, OVAL HD PH, SS
SM40447
1
40447 SPRING, RETURN
SM40449
1
40449 MOTOR, BRAKE
SM40450
1
40450 RUBBER, BRAKE
SM40451
1
40451 BRKT, BRAKE RUBBER MNTG,LEFT, OUTSIDE
SM40452
1
40452 BRKT, BRAKE RUBBER MNTG,LEFT, INSIDE
SM40453
1
40453 CAM, BRAKE
NA
1
40454 GUIDE, BRAKE CAM
SM40455
1
40455 SCREW, SET, #10-32 X .1875,
SM40456
1
40456 SCREW, #6-32 X .25, THR FORM, PAN HD PH
SM40457
1
40457
DIA. 3/8 X 1/2 LG SHLDR; 5/16 - 18 UNC X 1/2
LG THREADS; SOCKET HEAD
SM40458
1
40458 SCREW, #5-40 X .25, THR FORM, PAN HD PH
SM41269
1
41269 GROMMET, 2870, 7/8” ID
SM40358
1
40358 SHAFT, SWING ARM, BOTTOM, 5300
SM40364
1
40364 ROLLER, CAM
SM40381
1
40381 COVER, CRANK, STEEL
SM40416
2
40416 COVER, RIGHT REAR, FRONT
SM40417
2
40417 COVER, RIGHT REAR, BACK
SM40418
2
40418 COVER, LEFT REAR, FRONT
SM40419
2
40419 COVER, LEFT REAR, BACK
SM40420
2
40420 COVER, CAM, OUTSIDE, RIGHT
SM40421
2
40421
COVER, CAM, OUTSIDE, LEFT
SM40422
2
40422
COVER, CAM, INSIDE, RIGHT
SM40423
2
40423
COVER, CAM, INSIDE, LEFT
SM40426
2
40426
COVER, KNUCKLE, #1
SM40427
2
40427
COVER, KNUCKLE, #2
SM40428
2
40428 COVER, DEPENDENCY, UPPER, FRONT
SM40430
2
40430 COVER, DEPENDENCY LEFT, FRONT
SM40431
2
40431 COVER, DEPENDENCY, RIGHT, FRONT
SM40436
2
40436
DECAL,ID,RIGHT,5300
SM40437
2
40437
DECAL,ID,LEFT,5300
SM40438
2
40438 BRACKET, FRONT PLASTIC, SUPPORT
SM40439
2
40439 COVER, UPPER SWING ARM, #1
SM40440
2
40440 COVER, UPPER SWING ARM, #2
Service Parts List - EV916
