NAVMAN TRACKER 5507/5607 Installation and Operation Manual
71
GENERAL
Size
:
5507:
5.9” H x 6.5” W x 2.6” D
(150 mm H x 164 mm W x 65 mm D)
5607:
7” H x 7.7” W x 2.1” D
(179 mm H x 195 mm W x 54 mm D)
Display
:
5507: 5” diagonal, TFT color, 480 x 640 pixels
5607: 6.4” diagonal, TFT color, 480 x 640 pixels
Backlight: Display and keys
Supply voltage
10.5 to 32 V DC.
Supply current: at 13.8 V
300 mA min - no backlighting
550 mA max - full backlighting
External beeper or light output: Switched
to ground to sound alarm, 30 V DC, 200 mA
maximum.
Operating temperature
32°F to 122°F (0°C to 50°C)
ALARMS
:
User set: Arrival radius, anchor, XTE, danger,
dangerous AIS vessels, low fuel (optional), loss
of DGPS fix
Fixed: Loss of GPS fix
GPS NAVIGATION
Chart card: C-MAP™
NT-MAX, NT+ or NT
User card: 3.3 V C-MAP™
Waypoints: Up to 3000, with default or
user-defined alphanumeric names up to eight
characters.
Routes: 25 Routes, with up to 50 points each
Tracks: By time or distance, one track of 2000
points and four of 500 points.
Chart datums
121 Chart datums (see next page)
One user-defined map shift.
Chart scale: 0.05 to 4096 nm for chart (chart
dependent) down to 0.01 nm in plotter mode.
COMMUNICATIONS
NavBus
Connection to other NAVMAN instruments.
NMEA
NMEA 0183 ver 2 4800 baud
• Inputs from compatible instruments: DBT, DPT
(preferred), GGA, GLL, GSA, GSV, MTW, MWV,
RMC, VHW, VTG
Outputs, for compatible instruments: APA, APB,
BWR, GGA, GLL, GSA, GSV, RMB, RMC, VTG, XTE
STANDARDS COMPLIANCE
EMC:
USA: FCC Part 15 Class B.
Europe: (CE) EN301843-1:2004-06.
New Zealand and Australia: (C Tick) EN60945
9.2 & 9.3.
Environment: IPx6/IPx7/CFR46 (with card holder
and connections in place).
Appendix A - Specifications
