2-28 Hardware Installation
Installing the Terminal
The terminal can be mounted using the following mounts:
• Base for Retail I/O with Remote Power Supply (F033)
• Base for Hospitality I/O with Remote Power Supply (F035)
This chapter explains how to perform an "Out-of-box" installation of a CX7 configured
with the Base and how to connect optional peripheral devices.
The CX7 comes fully assembled and ready to use. All that is required to install is connect
the AC Power Cord, LAN Cable, and peripheral device cables.
For more information about the CX7 I/O ports, refer to:
• Retail I/O on page16
• Hospitality I/O on page17
