2-14 Hardware Installation
Installation Notes
Cable Restraint
The NCRPX10/PX15 POS (7746) includes cable management features to prevent
accidental disconnects and tampering. Some connectors include locking mechanisms
and cables that can be routed through the slot in the base.
Footprint
An area of no less than 45 square inches is necessary to properly install a PX10 unit with
MSR. This will accommodate the unit as well as its associated mounting hardware. For
terminals with customer display, refer to the NCRPX10/PX15 POS (7746) Site Preparation
Guide (BCC5-0000-5288) for specific dimensions.
Power
The NCRPX10/PX15 POS (7746) includes a 12V power supply as standard. With the
powered USB 24V option, a 24V external power brick is used. The source power of the
PX10/PX15 is drawn from a regular AC wall outlet. The electronics are “universal” – that
is, they will function when connected to standard wall outlets in most countries around
the world. For use in locales other than North America, special wall outlet adapters or
cables will be required. For international configurations, the country-specific power
cord is ordered separately.
Moisture
The terminal should not be installed in areas where it might be exposed to direct water
spray. PX10/PX15 units are not meant for outdoor installation.
Magnetic Stripe Reader (MSR) Cleaning
Caution: Prior to cleaning, please ensure that the terminal is not connected to a power
supply and not powered on.
Periodically, the MSR may need to be cleaned depending on usage. Pre-saturated MSR
cleaning cards can be ordered from NCR (50/box) using part number 1666-K024.
Otherwise, wrap a card with a saturated paper towel of glass cleaner and swipe gently
to clean the reader head.
Do not to use chlorine-based cleaners, such as Clorox bleach, non-chlorine bleach, or
chlorine-based bathroom or mildew cleaners. Also, do not use solvents such as acetone,
MEK, TCE, paint thinner, or turpentine.
Hardware Platform Drivers
The NCRPX10/PX15 POS (7746) uses the new NCR GEN3 drivers set. GEN3 drivers are
available on:
http://www5.ncr.com/support/support_drivers_patches_radiant.asp?Class=Hospitality/display
