4.
Exchange the fuse (250 V/8 A) on 084M-B1 PCB.
< T
op V
iew >
084M-B1
FUSE (8
A
/ 250 V)
Figure 4-3 Exchanging the Fuse
5.
Replace the Main-Cover and fasten two screws.
T
wo screws
Hooks
Main-Cover
Figure 4-4 Replacing the Main-Cover
SL1100
ISSUE 4.1 (R5.1)
4-2
Maintenance
117
