NEC DP-D-1D - Figure 2-46 Disconnecting the Battery Connection Cable; Figure 2-47 Loosen the Fuse Unit Screw

3. Disconnect the Battery connection cable from the Fuse Unit.
Battery Connection Cable
Fuse Unit
Figure 2-46 Disconnecting the Battery Connection Cable
4. Loosen the screw from the Fuse Unit.
Screw
Fuse Unit
Figure 2-47 Loosen the Fuse Unit Screw
5. Slide Fuse Unit out of the Battery box.
SL1100 ISSUE 4.1 (R5.1)
2-32 Installation
