Section 2: Customizing Features
DS1000/2000 Quick Setup Guide Section 2: Customizing Features ◆ 2-17
2
6. Press CONF to return to step 3 and add an extension to the Door Box Ring Group.
OR
Press
CONF twice to exit program 1802.
Part III: Program Analog Door Box Relay Control
To set up the relays for Door Box strike control:
1. Enter the programming mode. You see:
2. Enter
0201 + HOLD. You see:
3. Press
VOL Up until you see:
4. To have the analog Door Box plugged into DOOR1 activate its associated relay, dial
1 + HOLD + VOL
Up
. You see:
5. To have the analog Door Box plugged into DOOR2 activate its associated relay, dial
1 + HOLD + VOL
Up
. You see:
6. Press
CONF to exit program 0201.
To activate the relay for each Door Box:
1. Enter the programming mode. You see:
2. Enter 1801 + HOLD. You see:
3. Enter the extension number of the Door Box you want to program +
HOLD. You see:
4. Press
VOL Up until you see:
5. If the analog Door Box you are programming is connected to DOOR1, dial
1 + HOLD.
OR
If the analog Door Box you are programming is connected to DOOR2, dial
2 + HOLD.
6. Press CONF to go back to step 3 and select another Door Box.
OR
Press
CONF twice to exit program 1801.
Feature Quick Steps
To place a call to the Door Box:
● Lift handset and press ICM + Dial the Door Box extension number.
To answer the Door Box chimes from a keyset:
● Lift handset or press SPK.
To control the system relay which in turn controls the door strike.
● To open the relay, press FLASH key or OPEN soft key.
To close the relay, press
FLASH key or CLOSE soft key.
USER: nnn
ENTER PROGRAM?
0201:TENANT OPTIONS
CALL WAIT?nnn
0201:TENANT OPTIONS
DOOR1 RELAY?nnnn
0201:TENANT OPTIONS
DOOR2 RELAY?nnnn
0201:TENANT OPTIONS
PAGE ZONE?nnnn
USER: nnn
ENTER PROGRAM?
1801:EXTENSION PROG
EXTENSION #?nnn
1801:EXT:nnn
PT TYP?10:DOOR BOX
1801:EXT:nnn
RELAY OWNER?nnnn
