Section 1: Start-up Programming
DS1000/2000 Quick Setup Guide Section 1: Start-up Programming ◆ 1-5
1
Automatic Slot Configuration (DS2000)
DS2000 Automatic Slot Configuration automatically sets up station and trunk PCBs when you initially
power up the system. This simplifies installation because you no longer have to use system programming to
activate station and trunk PCBs after you plug them in. Here’s how Automatic Slot Configuration works:
● With power off, install your station and trunk PCBs.
With the system powered down, install the station and trunk PCBs from left to right in the order you
want your extension and trunk numbers set up.
- Be sure to install a 16DSTU PCB in the first slot (CN1).
- You don’t have to group your station and trunk PCBs together, although it may be more convenient to do
so. For example, when setting up a 16x32 system, you can install the 2nd DSTU PCB and your two
ATRU PCBs in any slot, in any order. Automatic Slot Configuration will properly handle the numbering.
● Power up the system.
On power up, the system scans the PCBs from left to right and sets up the extension and trunk number-
ing as follows.
- Extension numbers will begin with 300 in the first slot and increment from left to right.
- Trunk numbers will begin with 101 (starting from the first installed ATRU PCB) and will also incre-
ment from left to right.
Notes:
● System reset does not cause reconfiguraton. Automatic Slot Configuration is temporarily disabled dur-
ing a system reset.
● For more, see Automatic Slot Configuration (DS2000) and 9902 - Set Up Stations (DS2000) in the
Software Manual on your System Document CD.
Programming the System
How to Enter the Programming Mode
To enter the programming mode:
1. Go to any working display telephone.
2. Do not lift the handset.
3. Press ICM.
4. Dial # * # *
5. Dial the system password + HOLD.
Refer to the following table for the default system passwords.
See the Software Manual on your System Document CD for more on password levels.
6. Enter the number of the program you want to change (e.g., 1801) +
HOLD.
DSnnnn VER nn.nn.nn
PASSWORD:
Password Level Password Level
System Administrator 1
0000 1
System Administrator 2
9999 2
Installer
372000 3
USER: nnn
ENTER PROGRAM?
