NEC Express 5800 Series - Viewing the Diagnostic Report

Troubleshooting 104
Diagnostic report procedures
Viewing the diagnostic report
Procedure
1. Browse to the .zip file you created using the SSA.
2. Open the HTML file to view the report.
Identifying and viewing diagnostic report files
The diagnostic report output archive contains the following files:
 ADUReport.txt—Diagnostic report in text format
 ADUReport.xml—Diagnostic report in XML format
 ADUReportViewer.htm—HTML viewer for XML diagnostic report
 SlotX.txt (SlotX.old)—Controller serial output log
Procedure
1. Extract ADUReportViewer.htm to a directory.
2. Open ADUReportViewer.htm in the browser.
SmartSSD Wear Gauge report procedures
Viewing the SmartSSD Wear Gauge report
Procedure
1. Browse to the .zip file you created using the SSA.
2. Open the HTML file to view the report.
Identifying and viewing SmartSSD Wear Gauge report files
The SmartSSD Wear Gauge report output archive contains the following files:
 SmartSSDWearGaugeReport.txt—SmartSSD wear gauge report in text format
 SmartSSDWearGaugeReport.json—SmartSSD wear gauge report in JSON format
 SmartSSDWearGaugeReport.htm—HTML viewer for the JSON wear gauge report
Procedure
1. Extract the following files to a directory:
o SmartSSDWearGaugeReport.json
o SmartSSDWearGaugeReport.htm
All files must reside in the same directory.
2. Open SmartSSDWearGaugeReport.htm in the browser.
