NEC Express 5800 Series - Viewing Controller Status

SSA graphical user interface 35
Modifying power modes
Procedure
1. Open SSA. For more information, see "Using the SSA GUI."
2. Select the controller.
3. Click on Configure.
4. Click Modify Power Mode.
5. Select a power mode:
o Min Power
o Balanced
o Max Performance
6. Click OK.
7. A summary page appears. Click Finish to exit.
Viewing controller status
Use the SSA GUI to view the controller status, including the status of the cache and an attached battery or
capacitor.
Procedure
1. Open SSA. For more information, see "Using the SSA GUI."
2. Select a controller.
3. Click Configure.
4. Under Controller Configuration Summary, click View more details.
A new window appears.
5. Scroll down to Controller Status to view the status of the controller, cache, and battery or capacitor.
