19
2. Installation and Connection
Set VOLTAGE SELECT switch according to the voltage being used.
Voltage of power to use Power cable to use Position of the VOLTAGE SELECT switch
AC100V outlet AC100V power cable “100 130V–”
AC200V (single phase) outlet AC200V power cable “200 240V–”
Connect the power plug to the electrical outlet.
This completes the connection of the AC power supply cable.
To Next Page
